The trike was extremely easy to assemble. Only took about 20 minutes. Very comfortable to ride. Has plenty of power. I got up to 16mph on setting one and the range is amazing. I am very pleased with my purchase.






Assembly tools included
Yes
Range
45~75 MI
Top Speed
15.5MPH
Load Capacity
450 LBS
Motor
Peak 1310W
Foldable
Yes

Our approach to accessibility goes beyond physical design
And inclusivity, making sure every rider feels confident and empowered
It encompasses affordability, ensuring our E-Trikes are within reach
Size
Component
Specification
Configure

| ★Folded Size |
39.4(L) * 30.3(W) * 29.5(H) in 100(L) * 77(W) * 75(H) cm |
| ★Recommended Height | 5'-6'3" / 153-190 cm |
| A Top Tube Horizontal | 22 in / 558 mm |
| B Wheelbase | 36 in / 913 mm |
| C Stand Over Height | 16 in / 407 mm |
| D Handle Bar Length | 26 in / 660 mm |
| E Total Length | 66 in / 1670 mm |
| F Total Width | 29 in / 730 mm |
| G Seat Height Min / Max |
30.3~39 in 770~990 mm |
| H Handle Bar Height Min / Max |
43.7~45.7 in 1110~1160 mm |
| I Front Basket |
12.6 * 11.8 * 5.7 in 320 * 300 * 145 mm |
| J Rear Basket |
18.9 * 14.2 * 6.3 in 480 * 360 * 160 mm |
| K Wheel Size | 20" x 3.0 |
| LSeat Size |
11.8 * 10.6 in 30cm * 27 cm |
| Weight |
G.W. 112.4 lbs, N.W. 90.4 lbs
|
| Frame | 6061 Aluminum, Hydroformed Tubes |
| Fork | Shock Absorber Front Fork |
| Handle Bar | W: 660 * H: 120 * φ22.2 * 2.6T, φ31.8 |
| Stem | Adjustable 0-80d, L: 10.354 in |
| Grip | Soft PVC Rubber |
| Saddle | Seat with Backrest, Comfortable Large Vacuum-Foamed Seat |
| Seat Post | 6061-T6 Aluminum, φ1.25in x 21.65in Length |
| Seat Post Clamp | D40*25, Quick Release |
| Shifter | 6-Speed |
| Derailleur | Shimano |
| Chainwheel | 6.5in Alloy Crank, 38T Steel Chainring |
| Chain | KMC Z7 |
| Freewheel |
6S, 14-16-18-21-24-28T, Special Purpose for E-bike
|
| Pedal | Alloy Body, 9/16-inch |
|
Display
|
Intelligent Digital LCD Display Appears More Clearly in Sunlight, Color
|
| Brake | STARUNION Hydraulic Disc Brake, Alloy, 180mm Rotor |
| Brake Level | STARUNION Alloy 3-Finger Hydraulic Disc Brake with Electrical Cut-Off Function |
| Rim | 20-inch Alloy Rim, 3.0" Width, 13G Spokes, 36 Holes, AV |
| Tire | 20" x 3.0 Tire, CST, 60TPI |
| Spokes | 304 Stainless Steel, 13G |
| Parking Brake | With |
| Fenders | With |
| Rear Rack | With |
| Front Basket | With |
| Rear Basket | With |
| Assembly | 95% |
| Colors | 6 Colors |
| Carton Size |
39.8 x 29.9 x 30.3 inches 1010 x 760 x 770mm |
| Load Capacity |
450LBS
|
| ★ | Folded Size |
39.9(L) x 29.9(W) x 30.7(H) in 101.5(L) x 76(W) x 78(H) cm |
| ★ | Recommended Height | 5'~6'3" |
| A | Top Tube Horizontal | 20.9 in / 53 cm |
| B | Wheelbase | 44.1 in / 112 cm |
| C | Stand Over Height | 12.2 in / 31 cm |
| D | Handle Bar Length | 27.2 in / 69 cm |
| E | Total Length | 65 in / 165 cm |
| F | Total Width | 28.4 in / 72 cm |
| G | Seat Height Min / Max |
30.3~42.1 in 77~107 cm |
| H | Handle Bar Height Min / Max |
44.1~46.1 in 112~117 cm |
| I | Front Basket |
12.6 x 11.8 x 5.5 in 32 x 30 x 14 cm |
| J | Rear Basket |
18.9 x 14.2 x 6.3 in 48 x 36 x 16 cm |
| K | Wheel Size | 20" x 3.0 |
| L | Seat Size |
12.6 x 11.8 in 32 x 30 cm |
Assembly Video
Our assembly videos will walk you through assembly
Here we gather thousands of reviews from real users
This product is rated 4.8 of 5.0 stars.
It has received 64 reviews.
If you have any questions, you may get answers from here
When folded, the TK Pro Electric Trike measures 101.5 x 76 x 78 cm (39.9 x 29.9 x 30.7 inches), making it compact for storage and convenient to transport.
Arrives 95% assembled with simple final steps. Tools and clear instructions included for a quick, hassle-free setup.
Yes, indeed! Your trike arrives with a battery and both baskets included, ready for immediate use.
